CS-1672-A

Product Description

Specifications

• Application : Socket 370, A/462
• Support : Athlon 4, Athlon XP CPUs up to 2200+
• Overall Dia. : 75mm x 75mm x 536mm
• Weight : 450 g
• Material : Pure Cooper-C1020 with well surface treatment
  (Produced by Skiving Technology one piece structure)
• Thickness of Fin : 0.45mm
• Fins Pitch : 1.25mm
• Total Fins : 34 Fins
• Diemension of Heatsink : 61.5mm x 70mm x 26.5mm (H)
• Diemension of Fan : 74mm x 74mm x 15mm
• Speed : 5,600 R.P.M. (±10%)
• Bearing : Ball
• Rated Voltage : 12V
• Air Flow : 35.5 CFM
• Noise Level : 33 dBA
• Voltage : DC 12V
• Approval : CE, TUV, FCC (for Fan)
• Warranty : 3 years
• OEM/ODM : Available
